Rokasgrāmata Sharp HT-SBW53121(SL) Mājas kinozāles sistēma

Rokasgrāmata

EN

• If the device also supports Audio Video Remote Control Prole

(AVRCP), you can use the soundbar's remote control to play music

stored on the device.

1. Pair your device with the soundbar.

2. Play music via your device (if the Bluetooth device supports A2DP).

3. Use the soundbars remote control to control playback with the

and the

/ (if the Bluetooth device supports AVRCP).

NOTES:

ū The operational range between this soundbar and a Bluetooth device

is approximately 8 meters (without any object between the Bluetooth

device and the soundbar).

ū Compatibility with all Bluetooth devices is not guaranteed.

ū Any obstacle between this soundbar and a Bluetooth device can reduce

the operational range.

ū If the signal strength is weak, your Bluetooth receiver may disconnect, but

it will re-enter pairing mode automatically.

USB operation

1. Insert the USB device into the soundbar's USB socket.

2. Press the

button repeatedly on the soundbar or the remote

control to select the USB source.

3. You can navigate dierent folders stored on the USB device. Press

/

to change the folder.

4. Press

to play the selected track.

5. During playback:

ū To pause or resume play, press the

button on the remote

control.

ū To skip to the previous/next le, press the

/ buttons on the

remote control. Press and hold

/ to fast rewind / fast forward

a track.

TIPS:

ū USB devices up to 32GB are supported.

ū Only MP3/OGG/WAV/FLAC/AAC/AAC+/ALAC les can be played back.

The USB port is for playback or upgrading the software of the soundbar.

It is not for charging purposes.

Menu operation

Navigate the soundbars menu by using the remote control and pressing

. Use the directional control on the remote control to navigate the

available options. Press

to select the menu option. To select a setting

within a menu option, use

/ . Press to enter a sub-menu. Press

to return to the menu level above.

SURR

Turns Dolby Virtualiser or DTS Virtual:X ON or OFF. Dolby Virtualiser

aects Dolby Signals. DTS Virtual:X aects DTS and PCM signals.

NOTE:

ū SURR ON/OFF has no eect on a Dolby Atmos signal.

AUDIO FORMAT (scrolling)

Displays on the current audio format being played.

SUBVOL

Adjust the output volume of the subwoofer. Choose between VOL +5

and VOL -5.

SPKVOL

Opens the rear surround speaker volume sub menu.

SPK L or SPK R. Adjust the volume of each surround speaker.

Choose between VOL +5 and VOL -5.

MUTE. Change this setting to mute the rear speakers. Options are ON

or OFF.

NOTE:

ū The default setting is OFF. If switched ON, the rear surround speakers

will remain muted until they are unmuted, even if the system has been

in standby. Unplugging the soundbar from the mains power supply will

automatically switch muting OFF again.

DISP

You can change how many seconds elapse before the soundbars display

turns o.

Choose from: 5, 10 or ON. ON will keep the display active at all times.

DIM

You can change the brightness level of the soundbars display.

Choose from: LOW, MED, or HIGH.

STDBY

Change this setting to turn o the automatic standby option. Options

are ON or OFF.

The default is ON.

WLPAIR

Select this to manually pair the subwoofer and (optional) rear surround

speakers.

WL VER

Shows the current wireless subwoofer and rear surround speakers

software version.

SW VER

Shows the current software version of the soundbar.

SW UPG

Activates a software upgrade from an inserted USB stick.

NOTE:

ū This will only work with compatible software on a USB stick inserted into

the soundbars USB port. Periodically check www.sharpconsumer.com for

software updates.

RESET

Opens the reset sub menu.

Choose <Yes> to reset the soundbar. Choose <No> to exit or press the

button.

Room calibration and positional

adjustment

The volume of the subwoofer (and rear speakers if purchased

separately) can be adjusted relative to the soundbar. This manual

calibration allows for greater exibility when positioning the system

components in the room. The default volume for each component is set

to 0 and can be adjusted from -5 to +5. Based on the listening position,

the default volumes assume a distance of 2m from the subwoofer and

1.5m from the rear speakers. Use the <SUBVOL> or <SPKVOL> options

in the menu to balance the system to your preference. Once set, the

component volume will adjust with the soundbar volume to maintain

the system balance.

Troubleshooting

Q: Sometimes I notice minor distortions in voices played through the

rear surround speakers (available to purchase separately).

A: This should only occur when a 2.0 channel stereo audio source

is being upmixed to 5.1.4 or 7.1.4 channels. With 2.0 channel audio

formats, vocals are generally intended to be played from the soundbar

only (this is not always the case with multi-channel audio sources).

However, in some circumstances voices from 2.0 channel audio sources

cannot be separated reliably by the Dolby and DTS upmixer; the

result may be that you notice some voices are played through the rear

surround speakers at a low volume, and in some instances these voices
