Daily Reference Guide

2

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

SETTING MENU

1. Switch on the appliance by pressing the ON-OFF button.

2. Hold the Settings (Half Load ) button for 3 seconds until you hear

a beep.

3. After one second the rst available setting (letter “ ”) will be displayed.

4. Press button to scroll through the list of available settings (see table

below), then press START/Pause to view and change the value of the

currently selected setting.

5. Press to change the value, then press START/Pause to save the

new value.

6. To change another setting, repeat points 2 and 5.

7. Press ON-OFF or wait 30 seconds to exit the menu.

LETTER

SETTING

VALUES

(Default - in bold)*

Cycle Counter - number of washing cycles

carried out by the dishwasher.

Eg. 25 cycles: 25;

Eg. 13.947 cycles:

13_947

(scrolling

for 3 times)

Water Hardness Level

(see “SETTING THE WATER HARDNESS” and “WA-

TER HARDNESS TABLE”)

1 | 2 | 3 | 4 | 5

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

0 | 1 | 2 | 3 | 4 | 5

NaturalDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Sound

“1” = On, “0” = O

1 | 0

Factory Settings - press START/Pause to re-

store to the factory default all the values of the

settings included in the settings menu.

-

*) The default value does not apply to the Cycle Counter.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on

the dishes and on the machine’s functional components.

The salt reservoir is located in the lower part of the dish-

washer (under the lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the control

panel is lit.

1. Remove the lower rack and unscrew the reservoir cap (anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir right up to its

edge (approximately 0,5 kg); it is not unusual for alittle water to leak out.

3. Only the rst time you do this: ll the salt reservoir with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

Residual saline solution or grains of salt can lead to corrosion, irrep-

arably damaging the stainless steel components.

The guarantee is not applicable if faults are caused by such circumstances.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Using of Salt is recommended with any type of dishwasher detergent.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that the

water hardness setting is based on the actual water hardness in your house.

This information can be obtained from your local water supplier. The facto-

ry setting is “3”. See „WATER HARDNESS TABLE”.

Water Hardness Table

Level

°dH

German degrees

°fH

French degrees

°Clark

English degrees

1 (Soft) 0 - 6 0 - 10 0 - 7

2 (Medium) 7 - 11 11 - 20 8 - 14

3 (Average) 12 - 16 21 - 29 15 - 20

4 (Hard) 17 - 34 30 - 60 21 - 42

5 (Very hard) 35 - 50 61 - 90 43 - 62

To change, follow instructions in section “SETTING MENU”.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches o.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Using of Salt is recommended with any type of dishwasher detergent.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on the heater, contributing also to better cleaning ef-

ciency. This system regenerates itself with salt, therefore it is required

to rell the salt container when empty.

The frequency of regeneration depends on the water hardness level setting

- regeneration takes place once per 4-6 Eco cycles with the water hardness

level set to 3. The regeneration process occurs at the beginning of the cycle

with additional fresh water.

• Single regeneration consumes ~3 L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

A

B

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dis-

penser Ashould be lled when the RINSE AID REFILL

indicator light in the control panel is lit.

1. Open the dispenser B by pressing and pulling up

the tab on the lid.

2. Pour in the rinse aid (max. 110 ml), making sure it

does not overow from the dispenser. If this hap-

pens, clean the spill immediately with adry cloth.

3. Press the lid down until you hear aclick to close it.

NEVER pour the rinse aid directly into the appli-

ance tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satised with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow the instructions in the section “SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 6 levels can be set according to the dishwasher model.

• If you see bluish streaks on the dishes, set a low number (0-3).

• If there are drops of water or limescale marks on the dishes, set a mid-

range number (4-5).

FILLING THE DETERGENT DISPENSER

Only use detergent which has been specically designed for dishwashers.

DO NOT USE washing up liquid.

Using excessive detergent may result in foam residues remaining in

the machine after the cycle has ended.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

To achieve the best washing and drying results, the combined use of

detergent, rinse aid liquid and rened salt is required.

We recommend using detergents that do not contain phosphates or

chlorine, as these products are harmful to the environment.

Good washing results also depend on the correct amount of detergent

being used.

Exceeding the stated amount does not result in a more eective wash

and increases environmental pollution.

25 ml

35 ml

The amount can be adjusted to the soil level. In

the case of normally soiled items, use approxi-

mately either 35g (powder detergent) or 35ml

(liquid detergent) and additional tea spoon of

detergent directly inside the tub. If tablets are

used, one tablet will be enough.

If the crockery is only lightly soiled or if it has

been rinsed with water before being placed

in the dishwasher, reduce the amount of detergent used accordingly

(minimum 25 g/ml) e.g. skip the powder/gel putted inside the tub.

For good washing results also follow the instructions shown on the

detergent box.

FIRST TIME USE
